Adds a colourcoded surface of spatial objects (polygons, lines, or points
generated by extract_osm_objects
to a graphics object
initialised with osm_basemap
. The surface is spatially
interpolated between the values given in dat
, which has to be a matrix
of data.frame
of 3 columns (x, y, z), where (x,y) are (longitude,
latitude), and z are the values to be interpolated. Interpolation uses
spatstat.core::Smooth.ppp
, which applies a Gaussian kernel smoother
optimised to the given data, and is effectively nonparametric.
add_osm_surface( map, obj, dat, method = "idw", grid_size = 100, cols = heat.colors(30), bg, size, shape )
map  A

obj  An
dat  A matrix or data frame of 3 columns (x, y, z), where (x, y) are (longitude, latitude), and z are the values to be interpolated
method  Either
grid_size  size of interpolation grid
cols  Vector of colours for shading zvalues (for example,

bg  If specified, OSM objects outside the convex hull surrounding

size  Size argument passed to
shape  Shape of lines or points, for details of which see

modified version of map
to which surface has been added
Points beyond the spatial boundary of dat
are included in the surface
if bg
is not given. In such cases, values for these points may exceed
the range of provided data because the surface will be extrapolated beyond
its domain. Actual plotted values are therefore restricted to the range of
given values, so any extrapolated points greater or less than the range of
dat
are simply set to the respective maximum or minimum values. This
allows the limits of dat
to be used precisely when adding colourbars
with add_colourbar
.
# Get some data bbox < get_bbox (c (0.13, 51.5, 0.11, 51.52)) # dat_B < extract_osm_objects (key = 'building', bbox = bbox) # These data are also provided in dat_B < london$dat_BNR # actuall nonresidential buildings # Make a data surface across the map coordinates, and remove periphery n < 5 x < seq (bbox [1,1], bbox [1,2], length.out = n) y < seq (bbox [2,1], bbox [2,2], length.out = n) dat < data.frame ( x = as.vector (array (x, dim = c(n, n))), y = as.vector (t (array (y, dim = c(n, n)))), z = x * y ) if (FALSE) { map < osm_basemap (bbox = bbox, bg = 'gray20') map < add_osm_surface (map, dat_B, dat = dat, cols = heat.colors (30)) print_osm_map (map) } # If data do not cover the entire map region, then the peripheral remainder # can be plotted by specifying the 'bg' colour. First remove periphery from # 'dat': d < sqrt ((dat$x  mean (dat$x)) ^ 2 + (dat$y  mean (dat$y)) ^ 2) dat < dat [which (d < 0.01),] if (FALSE) { map < osm_basemap (bbox = bbox, bg = 'gray20') map < add_osm_surface (map, dat_B, dat = dat, cols = heat.colors (30), bg = 'gray40') print_osm_map (map) } # Polygons and (lines/points) can be overlaid as data surfaces with different # colour schemes. # dat_HP < extract_osm_objects (key = 'highway', # value = 'primary', # bbox = bbox) # These data are also provided in dat_HP < london$dat_HP cols < adjust_colours (heat.colors (30), adj = 0.2) # darken by 20% if (FALSE) { map < add_osm_surface (map, dat_HP, dat, cols = cols, bg = 'gray60', size = c(1.5,0.5)) print_osm_map (map) } # Adding multiple surfaces of either polygons or (lines/points) produces a # 'ggplot2' warning, and forces the colour gradient to revert to the last # given value. dat_T < london$dat_T # trees if (FALSE) { map < osm_basemap (bbox = bbox, bg = 'gray20') map < add_osm_surface (map, dat_B, dat = dat, cols = heat.colors (30), bg = 'gray40') map < add_osm_surface (map, dat_HP, dat, cols = heat.colors (30), bg = 'gray60', size = c(1.5,0.5)) map < add_osm_surface (map, dat_T, dat, cols = topo.colors (30), bg = 'gray70', size = c(5,2), shape = c(8, 1)) print_osm_map (map) # 'dat_HP' is in 'topo.colors' not 'heat.colors' } # Add axes and colourbar if (FALSE) { map < add_axes (map) map < add_colourbar (map, cols = heat.colors (100), zlims = range (dat$z), barwidth = c(0.02), barlength = c(0.6,0.99), vertical = TRUE) print_osm_map (map) }
